If you are interested in this product, please contact us for further assistance.

Features:

  • Patented PFA floating plug seal that is easily cleaned during CIP and offers outstanding sealing at high temperatures and excellent chemical resistance.
  • Body & plug shape provide minimal fluid retention area.
  • Rising plug or lowering plug type depending on the application.
  • Heavy-duty stainless steel pneumatic actuator that is capable of function changes:  NO (Normally Open) – NC (Normally Closed) – DA (Double Acting).
  • Clamp-style operator connection (manual and automated) for easy inspection and maintenance.
  • Heavy wall machined spherical bodies guarantee excellent resistance to thermal expansion and contraction.
  • Body configurations: DCX3 FdC (L).

Service Conditions

Max. temperature: 284°F (depending on seal type)

Min. temperature:  23°F

Sealing Pressure: 101 psi

Max. working pressure: 87 psi

Actuator air supply: 80 psi Minimum / 116 psi Maximum

Vacuum resistance: 0.4 cm3/s
