If you are interested in this product, please contact us for further assistance.
Features:
- Patented PFA floating plug seal & independent lifting plug seal that is easily cleaned during CIP and offers outstanding sealing at high temperatures and excellent chemical resistance.
- Body and plug shape provide minimal fluid retention area.
- Clamp-style operator connection (manual and automated) for easy inspection and maintenance.
- Heavy wall machined spherical bodies guarantee excellent resistance to thermal expansion and contraction.
- Clamp-style operator connection for easy inspection and maintenance.
- Heavy wall machined spherical bodies guarantee excellent resistance to thermal expansion and contraction.
Max. temperature: 284°F
Max. differential temp: 194° (between upper and lower line)
Min. temperature: 23°F
Max. working pressure: 58 psi (in the tank)
Max. working pressure: 87 psi (through the valve)
Sealing pressure: 101 psi
Actuator air supply: 80 psi Minimum / 116 psi Maximum
Vacuum resistance: 0.4 cm³/s
