Part NumberDescriptionSeal Type & MaterialWEG SS Motor

PCC-6142015-1MP1PX-BB-W3-8S2.00-316L

 2.00" IN x 1.50" OUT, 6" IMPELLER, 14TC FRAME D-TYPE / FDA BUNA 2.00 HP / 1800 RPM

PCC-6142015-3MP1PX-FF-W3-8S2.00-316L

 2.00" IN x 1.50" OUT, 6" IMPELLER, 14TC FRAME DG-TYPE / FDA FKM 2.00 HP / 1800 RPM

PCC-6212015-1MP1PX-BB-W3-6S10.0-316L

 2.00" IN x 1.50" OUT, 6" IMPELLER, 21TC FRAME D-TYPE / FDA BUNA 10.0 HP / 3600 RPM

PCC-6212015-3MP1PX-FF-W3-6S10.0-316L

 2.00" IN x 1.50" OUT, 6" IMPELLER, 21TC FRAME DG-TYPE / FDA FKM 10.0 HP / 3600 RPM

Features:

• Wetted surfaces are 316L stainless steel with a 32Ra grit polished sanitary finish.

• Port Connection: Clamp fittings are standard.

• Power: Supplied by a standard foot-mounted C-face motor in ranges from 0.5HP through 10HP.

• Type D seal material is carbon rotating on stationary stainless steel backplate. Suitable for dairy, water, beer and vegetable oil.

• Type DG uses the standard Type D rotating seal components with a reversible silicon carbide seat. Suitable for CIP solution, wine, spirits, wort and deionized water.

• Elastomers: Buna (D) and FKM (DG)

• Maximum impeller diameter allowed per housing is standard.
