Features:
- Direct Mount, easy to automate
- Sizes 1/2” to 6″
- Cavity filled and non-cavity filled
- ISO 5211 Mounting Pad
- 800/1000 PSI
- 316L Body Ball and Stem Full Port
- Sanitary clamp ends or extended tube OD ends
- An excellent choice for use in clean steam systems
- Excellent for Pharmaceutical and food & beverage
- 100% BPE compliant
- Full material traceability
Main valve components are made from 316L stainless steel
- Body and ends are 316L CF3M ASTM A-351 investment cast stainless steel
- The ball is machined from 316L CF3M ASTMA-351 cast stainless steel
- The stem is machined from ASTM A-493 316L bar stock
- Full traceability on all wetted parts (MTR’s)
- Standard internal polish is 15Ra and is polished to meet BPE specifications of part SF and tables SF-2.2-1, SF 2.2-2, and SF-2.4-1.
- Standard seats MPTFE (FDA, USP 23 Class VI)
Stem packing MPTFE - Full port to I.D. of tubing for reduced pressured drop
- Bottom entry 316L pyramidal lives loaded blow out proof high cycle stem adjusts to temperature and pressure fluctuation.
- Locked stem nut to prevent loosening after continuous valve actuation
- Dual anti-static devices on the stem (contact between stem and ball, and stem and valve body)
- ISO 5211 direct mounting pad
- Direct mount actuation 1/2” to 4”
- Handle locking device when manually actuated
- 3-piece body construction for ease of repair
- Open bolt design to facilitate full external cleanability
- Ends – Clamp, extended butt weld, or clamp by extended butt-weld.
- Clamp end requirements per BPE 2012 DT-7-1.
- Extended butt weld- 316L CF3M ASTM A351 controlled sulfur only per to BPE 2012 part MM section 5.1.1 and DT-3.1, DT-3.2, DT- 4.1, and DT-4.1.1.
Steel & O’Brien offers several different types of switch packages and control monitors for position feedback to PLC.
Optional integrally mounted or externally mounted solenoid valves are also available.
Options include….
Point-to-Point:
- Mechanical
- Proximity
- Namur
Network Type:
- AS-i
- DeviceNet
- Foundation Fieldbus
- Modbus
Manufactures available but not limited to Westlock, StoneL, Moniteur, Burkert, A-T Controls
Note: Not all platforms are available on all valve types. Consult the factory for availability depending on requirements.
