Features:
- 3-A Certified
- Replaceable elastomer seat due to 2-piece design
- Suitable for both process and CIP fluids
- Wetted construction in 316L material
- Standard size seat & body clamp
Tech Specs
Specifications:
End Connections: Clamp
Seat & Seal Material: FDA FKM (Standard), FDA EPDM (Optional)
Ball Material: FDA Virgin PTFE
Surface Finish: ID: 25-30Ra, OD: 32Ra
Maximum Operating Pressure: 150 PSIG
Operating Temperature: 30° F Min., 200° F Max.
