Features:
The valve can be mounted on the top of a pipeline or container to bleed a pipeline where an air pocket may have formed during operation.
Bleeding a pipe on the suction side of a pump will be automatic. Air binding will be prevented. These valves are found mounted on the top of the inlet pipe in front of the pump.
Ordering Information
Steel grade ……… Stainless steel, AISI 316L
Ball………………… Polypropylene
Finish……………… Polished to 32Ra
Tech Specs
Maximum product pressure ……150 PSI
Maximum temperature…………275°F
Net weight………………………19 oz. (9.5 kg)
For proper operation:
• Product density must be 1.0 or higher
• The valve must be mounted vertically
