Features:
- 316L SS wetted part construction
- Standard finish: 20RA ID (SF1) / 32RA OD
- Replaceable Tapered FDA/USP Class VI PTFE stem for positive closure
- FDA/USP class VI FKM O-ring stem seal
- Positive open stop to prevent accidental stem removal during operation
- Fully autoclavable without disassembly
- Thermoplastic black operator nut
- Full material traceability
In-Line Type Optional Features:
- Upgraded internal finish to 20RA W/ EP (SF5) OR 15RA W/ EP (SF4)
- Other material grades available upon request
- FDA/USP class VI EPDM O-ring stem seal
- Alternative end connections upon request
In-Line Type Service Conditions:
- Maximum operating temperature: 300° F
- Maximum operating pressure: 400 PSIG
- Maximum SWP:35 PSIG SWP @ 280° F
