Part NumberTOP-FLO® Ready-To-GoSizeSTP File

SV26TE10ASF1-20RA-316L

 Yes 1" T/C x 1/4" HB —

SV26TE10CSF1-20RA-316L

 Yes 1" T/C x 1/2" HB —

SV26TE10DSF1-20RA-316L

 Yes 1" T/C X 1/2" T/C —

SV26TE15ASF1-20RA-316L

 Yes 1-1/2" T/C x 1/4" HB —

SV26TE15BSF1-20RA-316L

 Yes 1-1/2" T/C X 3/8" HB —

SV26TE15CSF1-20RA-316L

 Yes 1-1/2" T/C x 1/2" HB —

SV26TE15CSF4-15RA-316L-EP

 Yes 1-1/2" T/C x 1/2" HB —

SV26TE15DSF1-20RA-316L

 Yes 1-1/2" T/C X 1/2" T/C —

SV26TE20ASF1-20RA-316L

 Yes 2" T/C X 1/4" HB —

SV26TE20BSF1-20RA-316L

 Yes 2" T/C x 3/8" HB —

SV26TE20CSF1-20RA-316L

 Yes 2" T/C x 1/2" HB —

SV26TE20DSF1-20RA-316L

 Yes 2" T/C x 1/2" T/C —

SV26TE50ASF1-20RA-316L

 Yes 1/2" T/C x 1/4" HB —

SV26TE50BSF1-20RA-316L

 Yes 1/2" T/C x 3/8" HB —

SV26TE50DSF1-20RA-316L

 Yes 1/2" T/C x 1/2" T/C —

SV26TE50DSF4-15RA-316L-EP

 Yes 1/2" T/C X 1/2" T/C —

SV26TE75ASF5-20RA-316L-EP

 Yes 3/4" T/C X 1/4" HB —

SV26TE75BSF1-20RA-316L

 Yes 3/4" T/C X 3/8" HB —

SV26TE75DSF1-20RA-316L

 Yes 3/4" T/C x 1/2" T/C STP

SV26TV10ASF1-20RA-316L

 Yes 1" T/C x 1/4" HB —

SV26TV10BSF1-20RA-316L

 Yes 1" T/C x 3/8" HB —

SV26TV10CSF1-20RA-316L

 Yes 1" T/C x 1/2" HB —

SV26TV10CSF4-15RA-316L-EP

 Yes 1" T/C x 1/2" HB —

SV26TV10DSF1-20RA-316L

 Yes 1" T/C x 1/2" T/C —

SV26TV15ASF1-20RA-316L

 Yes 1-1/2" T/C x 1/4" HB —

SV26TV15ASF4-15RA-316L-EP

 Yes 1-1/2" T/C x 1/4" HB —

SV26TV15BSF1-20RA-316L

 Yes 1-1/2" T/C x 3/8" HB —

SV26TV15CSF1-20RA-316L

 Yes 1-1/2" T/C x 1/2" HB —

SV26TV15DSF1-20RA-316L

 Yes 1-1/2" T/C x 1/2" T/C —

SV26TV20ASF1-20RA-316L

 Yes 2" T/C x 1/4" HB —

SV26TV20BSF1-20RA-316L

 Yes 2" T/C x 3/8" HB —

SV26TV20CSF1-20RA-316L

 Yes 2" T/C x 1/2" HB —

SV26TV20DSF1-20RA-316L

 Yes 2" T/C x 1/2" T/C —

SV26TV50ASF1-20RA-316L

 Yes 1/2" T/C x 1/4" HB —

SV26TV50ASF4-15RA-316L-EP

 Yes 1/2" T/C x 1/4" HB —

SV26TV50BSF1-20RA-316L

 Yes 1/2" T/C x 3/8" HB —

SV26TV50BSF4-15RA-316L-EP

 Yes 1/2" T/C X 3/8" HB —

SV26TV50CSF1-20RA-316L

 Yes 1/2" T/C x 1/2" HB —

SV26TV50DSF1-20RA-316L

 Yes 1/2" T/C x 1/2" T/C STP

SV26TV50DSF4-15RA-316L-EP

 Yes 1/2" T/C X 1/2" T/C —

SV26TV75ASF1-20RA-316L

 Yes 3/4" T/C x 1/4" HB —

SV26TV75BSF1-20RA-316L

 Yes 3/4" T/C x 3/8" HB —

SV26TV75BSF4-15RA-316L-EP

 Yes 3/4" T/C x 3/8" HB —

SV26TV75CSF1-20RA-316L

 Yes 3/4" T/C x 1/2" HB —

SV26TV75DSF1-20RA-316L

 Yes 3/4" T/C x 1/2" T/C —

SV26TV75DSF5-20RA-316L-EP

 Yes 3/4" T/C x 1/2" T/C —

Features:

  • 316L SS wetted part construction
  • Standard finish: 20RA ID (SF1) / 32RA OD
  • Replaceable Tapered FDA/USP Class VI  PTFE stem for positive closure
  • FDA/USP class VI FKM O-ring stem seal
  • Positive open stop to prevent accidental stem removal during operation
  • Fully autoclavable without disassembly
  • Thermoplastic black operator nut
  • Full material traceability
  • 100% BPE compliant

Concentric Optional Features:

  • Upgraded internal finish to 20RA W/ EP (SF5) OR 15RA W/ EP (SF4)
  • Other material grades available upon request
  • FDA/USP class VI EPDM O-ring stem seal
  • Alternative end connections upon request

Concentric Type Service Conditions:

  • Maximum operating temperature: 300° F
  • Maximum operating pressure: 400 PSIG
  • Maximum SWP:35 PSIG SWP @ 280° F
